Ubiquiti UniFi Access Point AC Mesh UAP-AC-M
The Ubiquiti UniFi AC Mesh (UAP-AC-M) is a compact dual-band Wi-Fi access point with wide-area coverage up to 600 ft, 250+ concurrent clients, and mesh technology for scalable deployments. With 867 Mbps on 5 GHz, 300 Mbps on 2.4 GHz, and PoE support, it’s perfect for hotels, campuses, outdoor hotspots, and enterprises.
Ubiquiti UniFi Access Point AC Mesh UAP-AC-M
With the Ubiquiti UniFi Access Point AC Mesh UAP-AC-M Wide-Area Dual-Band Access Point from Ubuiqiti Networks users benefit from a wide coverage area reaching up to 600′ along with enhanced data transfer rates of up to 867 Mbps on the 5 GHz frequency.
These enhanced data rates and coverage capabilities are supported by a 2×2 MIMO internal antenna configuration supporting multiple data paths for a more efficient end user network connection.
Installation of the UAP-AC-M is simple as it comes 802.3af PoE compliant and includes a wall/pole/fast-mount kit. Once installed users can take advantage of 802.11ac Wi-Fi access with speeds of up to 867 Mbps in the 5 GHz radio band, and up to 300 Mbps in the 2.4 GHz radio band.
The Wi-Fi system includes UniFi Controller software that can be installed on a PC, Mac, or Linux machine within the network, and is easily accessible through a standard Web browser.
Using the UniFi Controller software, an Enterprise Wi-Fi network can be quickly configured and administered, without any special training. Real-time status, automatic UAP device detection, map loading, and advanced security options are all seamlessly integr
ate
d in the system.
- High-Performance Wide-area Wi-Fi with UniFi® Mesh Technology
- Breakthrough speeds up to 867 Mbps in the 5GHz band
- 802.3af PoE compatibility
- 802.11 a/b/g/n/ac Wi-Fi Standards
- Range of up to 600′
- 1 x 10/100/1000 Ethernet port
- 2 x Integrated external omni dual-band antennas
- 250+ concurrent clients
Specifications for Ubiquiti UniFi Access Point AC Mesh UAP-AC-M
| Product | UniFi® AC Mesh Dual-Band Indoor/Outdoor Access Point w/ PoE |
|---|---|
| Part Number | UAP-AC-M |
| Standards | Wi-Fi 802.11a/b/g/n/ac |
| Interface | 1 x 10/100/1000 Ethernet port |
| Ports | 2 x Ethernet RJ45 1 x USB Type C |
| Memory | N/A |
| Antennas | 2 x External dual-band omni antennas |
| External Antennas | None |
| Antenna Gain in dBi | Maximum antenna gain of 3 dBi on 2.4 GHz Maximum antenna gain of 4 dBi on 5 GHz |
| Wireless Frequency Bands | Simultaneous dual-radio concurrent: 2.4 GHz 5 GHz |
| Speed Rates | 2.4 GHz: up to 300 Mbps 5 GHz: up to 867 Mbps |
| Data Rates | 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11ac: 6.5 Mbps to 867 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80 |
| Transmit/Receive | MIMO technology 2.4 GHz 2 x 2 5 GHz 2 x 2 |
| Range | Up to 600 ft. |
| PoE Modes | 24V Passive PoE 802.3af PoE: Alternative A |
| VPN Pass through | N/A |
| VLAN | Yes, 802.1Q |
| QoS | Advanced QoS Per-User Rate Limiting |
| Concurrent Clients | 250+ |
| Security | WEP WPA-PSK WPA-Enterprise (WPA/WPA2, TKIP/AES) |
| IP Rating | N/A |
| Buttons | Reset |
| LED Indicator | N/A |
| Power Options | 24 V Passive PoE (Pairs 4, 5+; 7, 8 Return) 802.3af Alternative A (Pairs 1, 2+; 3, 6 Return) (Supported Voltage Range: 44 to 57 VDC) |
| Power Supply | 24 V, 0.5 A PoE Gigabit adapter (included) |
| Power Consumption | 8.5W max. |
| Maximum TX Power | 2.4 GHz: 20 dBm 5 GHz: 20 dBm |
| Mounting | Wall/ Pole/ Fast-Mount (kits included) |
| Temperature | Operating: -30 ~ 70°C (-22 ~ 158°F) |
| Humidity | Operating: 5 ~ 95%, non-condensing |
| Certifications | CE, FCC, IC |
| Dimensions | 353 x 46 x 34.4 mm (13.9″ x 1.81″ x 1.35″) |
| Weight | 152g |
Package Contents
- Ubiquiti UniFi® UniFi UAP-AC-M AC Mesh Indoor/Outdoor Dual-Band Access Point
- PoE Gigabit Adapter
- User’s Information
